Extraction

• Vessel volume: 2 x 100 L or 2 x 200 L
• Liquid CO2 pump: Up to 22 kg/minute
• Integrated multi-solvent system
• Temperature range: 10–150°F (-12–65°C)
• Pressure range (standard configuration):
  • MAWP: 2,200 psi (151 bar)
  • Operating pressure: 500–2,000 psi (35–137 bar)
• Pressure range (high-pressure upgrade):
  • MAWP: 5,000 psi (345 bar)
  • Operating pressure: 500–4,800 psi (35–331 bar)

Separation & Collection

• Continuous CO2 purification
• Pressure range: 300–720 psi (21–50 bar)
• Temperature range: 40–100°F (4.4–38°C)
• Dedicated terpene collection
• Separate collection lines for each extraction vessel

CO2 Recovery & Storage

• Closed-loop CO2
• CO2 condenser
• CO2 remediation filters

Control Panel

• Multiple user levels
• Real-time monitoring
• Remote diagnostics / remote connectivity**
• Live batch recording

Continuous Operation

• Continuous cyclone separation*
• Dual extractor configurations

Specifications

• Weight: 7,915 lbs (3,590 kg)*
• Footprint (LxWxH): 252” x 124” x 157” (6.4m x 3.15m x 4m)*
