Power Sealer PLUS – Bulk Packaging
World’s most advanced validatable impulse sealer – when ultimate control of critical seal parameters is of paramount importance
When it comes to most precise validation, the PLUS is unmatched!
Discover our Flagship Power Sealer PLUS: a pneumatic bi-active impulse sealer with excellent and worry-free performance. Unique and accurate seal validation control software is integrated. The in-house designed Audion Touch Techware meets the most stringent packaging requirements in pharma and medical markets.
Power Sealer PLUS ensures the highest level of seal integrity: precise control of all critical seal parameters with most accurate tolerance measurements. This ensures each seal to be 100% reliable even during intensive use. Alarms can be set when seal temperature, seal force, effective seal time or cooling time come beyond tolerance.
The user-friendly Audion Touch Techware integrates the advanced Audion Temperature Controller and a clear HMI touchscreen for pre-setting 50 recipes and precise control of the critical seal parameters. Batch and cycle information can be stored and downloaded.
Specifications
Seal length: 520, 720 1020 and 1320 mm
Seal width: 8 mm
Validation feature: Seal force, seal temperature and seal time can be monitored, controlled, built-in alarm function, unmatched and most precise and accurate tolerances
Film thickness: 2 x 20 micron – 2 x 300 micron
Audion Touch Techware: High-end validation software with integrated Audion Temperature Controller (ATC), uniquely designed by Audion to meet the most stringest requirements in validatable packaging environments
Operation: Digital control panel, touchscreen HMI, 50 recipes
Type of seal: Temperature-, time- and force controlled impulse seal
Seal recipes: Up to 50 recipes can be stored (including machine height when combined with motorized support)
Data logging: Batch information of critical seal-parameters can be downloaded (USB stick)
Foot operation: Yes
Film type: Suitable for sealing various modern film types including thick films and special laminates
Covering: Stainless steel covering AISI 304
Classification: 2006/42/EC Machine Directive, 2014/30/EU EMC-Directive; RoHS 2011/65/EU, 2015/863; EN-ISO 11607-2, EN-ISO 12100, EN-ISO 4414, EN-ISO 14118, EN-IEC 60204-1
The Power Sealer PLUS stands for an uncompromised packaging experience. Audion designed various specific options to finetune this impulse sealer to your specific packaging environment.
Your Power Sealer PLUS advantages:
- World’s most accurate and precise validation compared to other validatable sealers in the market
- Optimization of your production workflow by means of a user-friendly HMI control panel
- Independant control of all critical process parameters
- All our PLUS series impulse sealers are compatible with EN 868-5 and DIN 58953, part 7 norms. Our PLUS series impulse sealers also fully comply with the ISO 11607-2 and ISO/TS 16775
- Maximizing your output with minimum production failures/waste
- Foot pedal activation
- Excellent customer service available for both certified (re)-calibrations and delivery of most (wearing) parts directly from stock.
This makes your machine unique
We work together with you in providing the best quality packaging machines to help you grow your business
Richly equipped as standard
The robust stainless steel housing, solidly mounted sealing bars and Audion Touch Techware make this packaging solution the most advanced tech magic in its class, reaching the highest degree in validation and seal integrity.
Combine user-friendliness with ultimate control
Ultimate quality assurance of every seal, easily monitored and controlled on the HMI Touchscreen. Most precise and accurate control of all critical seal parameters, including alarm functions and data logging.
Wide selection of options for the best fit
From the wide experience in medical and pharma market we innovated an extensive list of options to customize your Power Sealer to the ultimate fit to your product and packaging environment.
Ergonomic packaging
Do you prefer a tabletop model or the Power Sealer being mounted on a mobile support? By mounting the Power Sealer on the sturdy stainless steel mechanical or motorized support you ensure yourself of an optimized packaging posture. Adjustable height of the sealer can be set in the sealer’s recipe (motorized support).
